Home Products & Solutions Polymer Process Injection Molding Solutions Product Toggle-clamping Hydraulic Injection Molding Machine A5 SERIES 3rd Generation Servo Hydraulic General Purpose Injection Molding Machine

With larger specifications and faster response, wider processing range and lower repeated investment costs. Optimized injection units ensure precision and stability. Uniform-stress molding technology provides durability and reliability. Available with clamping forces from 600 to 5,600 kN.
Precise and stable

High-efficiency and energy-saving

Uniform-stress clamping technology

Closed-loop control of mold open position

Machine Introduction Video

Machine Introduction Video
Clamping Unit
High-rigidity T-slot platen
Increases the overall rigidity of clamping unit by 30%, brings convenience for installation and removal of mold, reduces the wear of thread due to long-term use of screw hole and extends the life of platen.
Closed-loop control of mold open position
The mold open position accuracy is smaller than 2mm and repeatability is below 0.3mm.
Anti-tilt platen support design
Increases the smoothness of motion, lowers friction, improves the efficiency of motion, reduces energy consumption and prevents the platen from tilting so as to protect the mold.
Injection Unit
Integrated linear guide rail structure
One-piece supporting base integrates with linear guide rails, which minimizes the friction to motion, increases injection accuracy and enhances plasticizing efficiency.
Horizontal dual-carriage design
Effectively eliminating rotary torque to ensure a reliable and stable injection.
New universal screw and barrel unit
Further optimizes color mixing and plasticizing efficiency, easy color change and cleaning, low shear without temperature rise and wider applicability.
Yizumi’s third-generation energy-saving servo technology
To achieve superior performance in stability, reliability, durability, energy conservation, efficiency and low noise, the servo system uses 30%-80% less energy than conventional hydraulic machines. The accuracy of closed-loop hydraulic oil temperature control, which is the new function, is ±0.5℃ with further increased stability.
Mirle MK500 control system
The control unit adopts Cortex-A55 processor with scan time of 0.25ms, speedy response and accurate control.
1000 sets of mold data memory, USB port for extension of storage.
7+1 sections of PID temperature control supports switchover between type J and type K thermocouples. Automatic PID tuning improves the temperature control accuracy.
Integration of common software (like IMC, robot, needle valve) meets different injection molding process requirements.
